Medical Logistic Drone

The Medical Logistic Drone is an unmanned aerial system specifically designed to support the distribution of medical supplies and first aid assistance during military operations. Developed to enhance medical response on the battlefield, it is especially valuable in high-risk or hard-to-reach locations.

This drone enables rapid medical resupply, front-line delivery of health logistics, battlefield reconnaissance, and transport of aid to wounded soldiers. Larger variants can also support light casualty evacuation (CASEVAC).

For the Indonesian Army Infantry Unit (TNI AD), this drone ensures swift and secure casualty handling. For the Medical Unit (Kes TNI AD), it extends healthcare delivery in operational zones, boosts logistical effectiveness, and reduces personnel risk.

Technical Specifications

• Payload: 10 kg
• Range: 8 km
• Dimension: 1216 x 630 mm ± 25 mm
• Flight Time: 45 minutes
• Total Weight: 14 kg
• Flying Speed: 0 - 15 m/s
• Flying Height: 0 - 200 m
• MTOW: 14 kg
• Landing Approach: Vertical Take-Off and Landing (VTOL)
• Battery: 12s 16000 mAh LiPo Battery
• Transmission Distance: 8 km
• Container Material: Plastic

Sensor Specifications

• Imager Sensor: 1/2.8" Sony CMOS
• Effective Pixel: 5.13 MP
• Digital Zoom: 32x
• Angle of View (H): 69.9° (Wide) ~ 8.7° (Tele)
• IR Thermal: Optional

Production Capacity

Our facility can produce up to 30 units per month. With fully domestic production, we offer competitive pricing without compromising on quality or reliability.
